Product descriptions
9 circulating water pumps are ordered, including motors, expansion joints, electric butterfly valves and steel outlet pipes, which are all part of the associated equipment, for 3 power generator sets. The entire installation helps increase power generation against power rationing in the heat of summer.
Product specifications
CWP flow rate: 9.5 m3/sec; lift: 14.5m; outlet dia.: 2,500mm; rated HP/rpm of motor: 1,900kw/rpm
Product function
The pump is driven by a coupler which is in turn driven by a motor to draw seawater 24 hours /day non-stop. The water is ejected after cooling the generator boilers. The steam is cooled down swiftly into water, and the water is circulated to boiler to heat up and generate steam again.
-
Dalin Power Plant CWP Manufacture and Installation Project
Build 6 CPWs, for use by 2 generation sets to increase power output and thereby prevent power curtailments in summer
-
TPC Hsingta Plant GGH-FGS Waste Heat Recovery Performance Enhancement
The project includes two gas-to-gas heaters (GGHs); each is equipped with the cooler and reheater
